The Siemens Sinamics G120X drive is a simple, seamless, and easy-to-use drive, designed for use in pump, fan, and compressor applications in industries such as water/wastewater, HVAC/R, irrigation/agriculture, and in industrial environments.
Ready to go right out of the box, the G120X offers outstanding ease of use. It's simple to commission and operate using its high-resolution graphical color keypad, known as IOP-2 (intelligent operator panel), as well as the optional Wi-Fi-enabled Smart Access wireless module — both optimized for pump and fan applications.
The G120X drive is energy, as well as cost-efficient, robust, reliable, application/industry savvy, and ready for digitalization! Check out all these features that deliver new levels of simplicity and reliability...
SINAMICS G120X: X-factors for improved pump/fan performance
- Easy to set up
- Easy to program and use
- Reliability and service life
- Reduced maintenance
- Easier integration and digitalization
- Consistent with SINAMICS drives
- VII. UL rated rugged duty
- Long cabling for ease of install
- Easy to design and specify
- X. Siemens expertise
It has a wide power range from 1–700 hp (0.75–630kW) and very wide voltage ranges 3AC 200–240V, 380–480V and 500–690V with operating temperatures from -4º to 140º F (-20º to 60º C) and is available with 3C3 coated circuit boards to withstand hydrogen sulfide, sulfur dioxide in addition to other corrosive gases and harsh environments. The G120X can work with any induction, permanent magnetic and synchronous reluctance motor — mastering every challenge of your customer’s industrial application. It has an integral DC choke which improves harmonics and EMC performance. Sinamics G120X meets all the latest and upcoming UL, NEMA and EN/IEC standards for 2019 and beyond and offers up to 100 kA short-circuit current rating (SCCR) ensuring enhanced product safety and energy efficiency.
Saving you time!
- Select and order in no time with the DT Configurator Tool
- Fast and simple ordering process with a single catalog number (article number) to order a complete drive with control unit and operator panel (IOP-2) in a single box
- Compact and ready to switch on and set up to run a motor of matching power right out of the box
- Easily integrates into existing applications
- Wide power and voltage ranges up to 700 hp (630 kW) with same look, feel and user interface
- Simple to set up and operate using its high-resolution graphical color keypad, known as IOP-2 (intelligent operator panel), as well as the optional Wi-Fi-enabled Smart Access Module — both optimized for pump and fan applications
Improved longevity and reduced downtime!
- Optional “special” coating (Class 3C3) on the power boards for operation in harsh environments (where corrosive gases such as Hydrogen Sulfide (H2S) are present)
- Improved EMC and grid (harmonics) performance due to integral DC choke (FSA-FSG, up to 400 hp / 250 kW)
- Standard warranty 24 months + an additional 6 months with product registration
Cost-optimization + resource-saving operation reduce the cost of ownership
- Integral DC choke (FSA-G) eliminates the requirement of an external line reactor
- Designed to deliver constant power at a current according to NEC table 430.250 at 3AC 480V and 600V, and at an operating temperature of 45ºC without derating, and up to 55 ºC with derating
- Increased motor cable lengths up to 450 meters (1476 ft)1) without output choke or filter
- New design feature enables UL Open Type / IP20 drive in to push through type using an optional add-on Push-Through (PT) kit2), which reduces or eliminates need for cabinet fans, associated components and wiring, and also facilitates cost-efficient NEMA/UL Type 1, 12 or 3R designs with an appropriately NEMA/UL-rated external enclosure
Application/industry segment savvy
- Built-in features and functions dedicated to industrial pump, fan and compressor applications
- Provides enhanced product safety through UL61800-5-1 certification (CULUS) up to 100kA SCCR which makes SINAMICS G120X exclusive in the industry for the focused segments — i.e. industrial pump, fan and compressor, water/wastewater, HVAC and irrigation markets
- Hardware-based SIL3-rated Safe Torque Off (STO) function with a switch to activate or deactivate this safety function
More efficient system integration, monitoring, and service
- Convenient, user-friendly setup and diagnostics with Wi-Fi enabled Smart Access Module (SAM)
- Simple connection to cloud-based analytics with SINAMICS Connect 300
- Communication via PROFINET, EtherNet/IP™
- TIA portal via GSD file
Discover how to easily set up SINAMICS G120X converter
using the IOP-2 panel and control via I/O terminals.
SINAMICS G120X meets all the latest industry standards with regard to energy efficiency and product safety and offers enhanced safety with SIL3 rated safety functions and up to 100kA short-circuit current rating according to UL61800-5-1.
-
Download the Technical Overview Brochure
-
Configure Your G120X Quickly & Easily
(Be sure to check out the video below...)
